Outoor IR Thermal Camera Helping The Driver To Detect Distant

Availability:

PDF Export

  • AGT- VTC256

Key Benefits:

  • Key Benefits:

  • Safe driving in total darkness.

  • See through dust and smoke.

  • Prevent high beam glare interference.

  • Super long sight distance.

  • Intelligent Early Warning to avoid accidents.

  • helping the driver to detect distant pedestrians and animals in advance

thermal security camera system


Overview:

  • Thermal imaging is based on the surface of the object and does not depend on the light source. It can still achieve clear imaging in dark areas at night, effectively helping drivers to detect people and vehicles outside the light range in advance.

  • Prevent high beam glare interference.Thermal imaging is not affected by the other party's high beam or other strong light to help the driver see the road ahead clearly even when the high beam is illuminated.

  • Super long sight distance. It can provide clear infrared images in the range of 300 meters, which is twice that of ordinary car high beams, greatly improving the driver's vision, and actively helping the driver to detect distant pedestrians and animals in advance.

  • Intelligent identification and alert. Identify pedestrians 80m ahead and vehicles 110m ahead, and issue sound and image alarms for possible collision dangers, allowing drivers to calmly deal with various dangers.


Technical Specification:

Model

AGT-VTC256

Detector Type

Vox Uncooled Infrared Focal Plane

Spectral Range

8~14 μm

Resolution

256×192

Lens

Focal length:9.0mm

F 1.0

FOV:20°* 15°

Pixel Pitch

12μm

NETD

<50mK @25℃,F#1.0,25Hz

Detector Frame Rate

≤25Hz

Non-uniformity Correction

Automatic shutter correction

Image Showing

White hot

Image Enhancement

Automatic

Boot time

≤15s

Power input

9~36V

Intelligent Early Warning

Contains human and vehicle identification algorithm and realizes intelligent early warning

Recognition distance

People(1.8x0.5m)≤ 80m

Vehicle(2.3x2.3m)≤ 110m

Weather conditions: 25℃,60%RH,

Detection distance

People(1.8x0.5m) 180m

Vehicle(2.3*2.3m)280m

Weather Condition:25℃,60%RH,

Video Output

USB/CVBS

Communication Interface

RS232

Lens Protection

High-strength protective window

Working Temperature

-40℃~80℃

Protection Class

IP69 (thermal imaging camera)

Dimensions

Camera module≤55x32x32 ( LWH mm)

Controller Module≤110x100x25( LWH mm)

Weight

60g(Camera module)

380g(Controller module)

Accessories

Universal Mounting Brackets, Harnesses, Accessories
