DRC19 series high speed laser night vision dome camera, 2.1 megapixel, can monitor a region of 300m~400M clearly at night. Consist of NIR laser illumination, PT, precise gearing, HD lens, digital encoder, CCD and MCU. The mechanical design of PTZ is simple and stable. It could rotate to the proposed position quickly and accurately.
The camera has 128 presets, recording and patrol function and could preset anywhere. It also have automatic exposure, automatic focus function.
50°laser illuminator, 2.1 MP HD CMOS, max illumination distance 300m-420m.
Unique DSS laser angle control, min 0.1°sync zoom accompany camera, support manual zoom and sync zoom.
Unique GHT laser homogenizing technology.
Independent photo-resistor switch make sure the camera color mode and laser on/off at the same time. Built-in intelligent delay to avoid the influence of car light.
All metal cooling housing, CGS cooling system and double sun block, night vision module cycle air-cooling.
SDE image detail enhancement technology, no noise, B/W and B/W inverse color mode.
Multi-bearing structure.
Support online software update.
Electric motor drive, reaction quick, rotation smoothly, tolerance less than 0.1°.
Support 3D intelligent positioning function, click tracking enlarge.
Address and protocol DIP switch is on the side.
Weatherproof rate IP66, anti-rain, anti-dust, TVS4000V anti-lightin.
Seaport and airport monitoring;
Water system monitoring;
Storage monitoring;
Military base security monitoring;
Oilfield & oil depot security;
Fire source prevention & monitoring;
Ecological and environmental monitoring;
Border and coastal defense;
Urban security and anti-UAV applications;
Highways and railways monitoring.
City Safety, stadium/plaza/scenic spot monitoring, oilfield safety, lake&river monitoring, freeway&railway security, seaport&airport security.
Model | AGT-DRC1930 |
Detection | Day:800m; |
Night: 400m | |
CCD | 1/2.8'' CMOS, HD 2.1 MP, 1920X1080, Auto ICR switch, color to B/W mode |
Video encoding | Video compression H.264, code stream 32k~8Mbps, Support dual-stream,the heart, smart restructuring,electronic shutter, white balance, 3D DNR, DWDR,automatic exposure, support SD card, motion detection, mask alarm |
Focal length | 4.3~129mm,30 optical zoom F1.6~F5.0 |
FOV | 65°~2.3° |
Min. illumination | 0.05lux /0.005lux |
Consumption | 5W, 808nm,NIR |
Laser lens | 30mm F1.0 Fast lens, GHT laser homogenizing technology |
Laser angle | 2°~50° |
Angle control | DSS laser angle control technical, 30ms fast track response,min 0.1°sync zoom accompany camera, support manual zoom and sync zoom. |
Optical axis aiming | 0.01°SLM optical axis aiming and locking |
Laser on/off | Auto/manual |
PTZ | Pan: 360°continuously, Tilt: -90°~+5°(Support auto reverse) |
Rotation speed | Pan: 0.01°~200°/s, Tilt: 0.01°~120°/s, max speed of calling preset 250°/s, rotation speed vary automatically according to the focal length |
Preset | 255, support memory record after power breakdown, scan, keep watch |
Interface and protocol | RJ45, 10M/100M Ethernet, TCP/IP, RTP/RTCP, HTTP etc protocol |
Compatibility | Support ONVIF,GB/T28181 |
Customized function | Customizable privacy shade, 3D box chosen magnification |
Online update | Support online update |
Baud rate | 2400/4800/9600/19200bps |
Weatherproof | IP66, TVS4000V anti-lighting, anti-wave |
Operational temp. | -30℃~60℃, <90%RH non-condensing |
Power supply | DC12V/4A, common≤40W,peak≤60W |
Dimension | Φ230(mm)*348(mm) |
Weight | 5kg |
