Key Benefits：
DSS digital stepper illumination angle control, unique laser zooming and distance matching technology, min 0.1° follow-up zooming
GHT-II super homogenizing and power consumption control of NIR laser ensure a better effect．
Convenient for installation and application independent photosensitive control circuit, precise synchronous switching of laser switch and camera into day-night mode
Precise double optical alignment, 0.01° SLM optical self-locking alignment
Heavy duty PT, 360° continuously rotation observation, no dead angle, smooth and less image dithering.
One integral aluminum alloy housing, IP66 ingress protection, waterproof, dust-proof, adapt to all kinds of harsh environment.
Overview：
Consists of HD Visible Camera + NIR Laser Illuminator which suitable for 24hours monitoring.
The maximum detection distance for human/car/object is 4km during day time and 2 km in the night
With built-in technical grade embedded control electronic system, the camera operates stable and accurate when zooming, focusing, video switch, and during rotation.
Applications：
Seaport and airport monitoring;
Water system monitoring;
Storage monitoring;
Oilfield & oil depot security;
Fire source prevention & monitoring;
Ecological and environmental monitoring;
Border and coastal defense;
Urban security and anti-UAV applications;
Highways and railways monitoring.
Technical Specification：
| Model | AGT-RC2075 |
Detection Distance | Night:2000m, Day: 4000m |
Visible Light Camera | Sensor：Back-illuminated ultra-low illumination starlight CMOS Lens: 12.5～775mm |
Laser Illuminator | 808nm 15W |
Latest infrared GHT-III HD laser homogenization light source, 600μm cross-sectional imaging lens, multi-layer near infrared antireflection coating, high-efficiency laser coupling | |
Smart Function | Latest analysis: intrusion detection, cross-line detection, entry/exit detection, automatic tracking, intelligent information overlay, sound and light alarm, privacy mask, alarm management |
Distance and Angle Matching | Automatic tracking/manual fine-tuning intelligent matching; DSS digital lighting angle control, with an accuracy of 0.1°; Laser angle and imaging magnification matching algorithm; Laser synchronization effect adjustment switching mode; SLM double optical axis self-locking alignment, accuracy 0.01° |
Pan Tilt | Load: 30Range: Level 0～360°, pitch -45°～+45° Speed: Level 0.01°/s～30°/s, pitch 0.01°/s～15°/s Preset ≥255 |
Electrical Interface | 1 * RJ45, 10/100M adaptive Ethernet port; 1 * DC24V Alloy waterproof aviation plug |
